AM-501

power supply
Input voltage: 100~240VAC, 50/60Hz
Rated power: 70W@220V


optics

Light source: 50W LED
Color rendering index: RA≥85
Color temperature: 3200K, 4000, 5600K optional


Effect

Vertical scan: manual rotation 360°
Strobe: 0~30HZ
Dimming: 0-100% linear adjustment


control

Control mode: DMX512
Channel: 1CH/2CH/4CH
physical properties
Protection class: IP20
Shell: high-strength die-casting aluminum, black (customizable color)
Wire: 1.5m pure copper hand in hand wire
Product net weight: 1.95kg
Working environment: -20℃~40℃
Lamp size: 134x107x126mm

Packing size: 200x120x260mm
